Mercury 225 EFI User Manual

1
2
3
4
5
6
7
General Information
& Specifications
Electrical
Fuel System
Powerhead
Mid-Section
Gear Housing
Attachment/Control Linkage
8
Color Diagrams
90-884294 OCTOBER 2001 Page iii
Service Manual Outline
Section 1 - General Information & Specifications
A - Specifications
B - Maintenance
C - General Information
D - Outboard Installation
Section 2 - Electrical
A - Ignition
B - Charging & Starting System
C - Timing, Synchronizing & Adjusting
D - Wiring Diagrams
Section 3 - Fuel System
A - Fuel Pump
B - Fuel Injection
C - Oil Injection
D - Emissions
Section 4 - Powerhead
A - Powerhead
B - Cooling
Section 5 - Mid-Section
A - Clamp/Swivel Brackets & Drive Shaft Housing
B - Power Trim
Section 6 - Gear Housing
A - Right Hand Non-Ratcheting
B - Left Hand Non-Ratcheting
Section 7 - Attachments/Control Linkage
Section 8 - Color Diagrams

Mercury 225 EFI Specifications

General

Engine Type	V6
Horsepower	225 hp
Steering	Remote
Fuel Induction System	Electronic Fuel Injection (EFI)
Alternator Output	60 Amp
Shaft Length	20", 25"
Weight	505 lbs
Full Throttle RPM Range	5000-5800
