Micom P631 - Page 581

OUTP: Fct.assignment K xxx Fig. 3-29, (p. 3-45)
Fig. 3-36, (p. 3-57)
OUTP: Oper. mode K xxx Fig. 3-29, (p. 3-45)
OUTP: State K xxx Fig. 3-29, (p. 3-45)
Signal 1 EXT Fig. 3-148, (p. 3-179)
Signal 2 EXT Fig. 3-148, (p. 3-179)
THRM1: Block. by CTA error Fig. 3-113, (p. 3-148)
THRM1: I Fig. 3-114, (p. 3-149)
THRM1: With CTA Fig. 3-113, (p. 3-148)
A2 Internal Signals
P631
P631/EN M/R-11-C // P631-310-650 A2-3
