MINI Hawk High Performance Imager User’s Manual 1-1

1 Quick Start

Contents

This chapter is designed to get your MINI Hawk up and running quickly, using the EZ button

or ESP (Easy Setup Program). Following these steps will allow you to get a sense of the

imager’s capabilities and to test sample symbols.

Detailed setup information for installing the imager into your actual application can be

found in the subsequent chapters.

Step 1 Check Required Hardware ................................................................................................1-2

Step 2 Connect the System .......................................................................................................... 1-3

Step 3 Position Imager and Symbol..............................................................................................1-4

Step 4 Install ESP......................................................................................................................... 1-5

Step 5 Select Model...................................................................................................................... 1-6

Step 6 Select Protocol and Connect.............................................................................................1-7

Step 7 Locate the Symbol in the Field of View .............................................................................1-9

Step 8 Calibrate ......................................................................................................................... 1-11

Step 9 Test Read Rate .............................................................................................................. 1-12

Step 10 Configure the Imager in ESP........................................................................................ 1-13

Step 11 Save Configuration in ESP........................................................................................... 1-14
