A-8 MINI Hawk High Performance Imager User’s Manual
Serial Configuration Commands
Appendix C — Serial Configuration Commands
Note: For a list of utility commands such as read rate requests, device control options, and
imager status requests, see Serial Utility Commands on page 13-2.
Communications
Host Port Connections <K100,baud rate,parity,stop bits,data bits>
Auxiliary Port Connections <K101,aux port mode,baud rate,parity,stop bits,data bits,daisy
chain ID status,daisy chain ID>
RS-422 Status <K102,status>
Host Port Protocol <K140,protocol,address>
Preamble <K141,status,preamble characters>
Postamble <K142,status,postamble characters>
Response Timeout <K143,response timeout>
LRC <K145,status>
Auxiliary Port System Data Status <K146,aux>
ACK/NAK Options <K147,RES,REQ,STX,ETX,ACK,NAK>
Polling Mode Options <K148,RES,REQ,STX,ETX,ACK,NAK>
Autoconfiguration Daisy Chain <K150DAISY>
Calibration
Calibration Options <K529,gain,shutter speed,focus position,symbol type,WOI framing,
WOI margin,line scan height>
Autocalibrate
<
@CAL
>
Read Cycle
Trigger Mode/Filter Duration <K200,trigger mode,leading edge trigger filter,trailing edge trigger
filter>
Serial Trigger Character <K201,serial trigger character>
External Trigger State <K202,external trigger state>
End of Read Cycle <K220,end of read cycle,read cycle timeout>
Minimum Good Reads <K221,minimum good reads>
Multisymbol <K222,number of symbols,multisymbol separator>
Start Trigger Character <K229,start character>
Stop Trigger Character <K230,stop character>
Capture Mode <K241,capture mode,number of captures,rapid capture mode>
Capture Timing <K242,time before first capture,time between first and second
captures,,,,,,,,time between seventh and eighth captures>
Image Storage <K244,image storage type,image store mode>
IP Timeout <K245,image processing timeout>
Symbologies
Narrow Margins/Symbology ID
<
K450,
narrow margin status,symbology identifier status>
Background Color <K451,background color>
Composite <K453,symbology status,separator status,separator>
Aztec Code <K458,status>
Micro QR Code <K459,status>
