12-2 MINI Hawk High Performance Imager User’s Manual
Terminal Window
Terminal Window
The following view will appear:
The Terminal screen allows you to send serial commands to the imager by using Macros,
by copying and pasting, or by typing commands in the Send text field.
The Terminal screen also displays symbol data or information from the imager.
You can also right-click on the Terminal screen to bring up a menu of further options.
Click this button to display the Terminal view.
Click on desired
Macro to run.
Click on Macros arrow to Add Macro,
Remove Macro, or Edit Macro.
Copy, paste, save
Type text here to
find matching text
in the Terminal
window.
Type serial
commands
here.
Macros listed
on this bar
Clear screen
Terminal
screen
To Next Page
