Microscan MINI Hawk - Navigating in ESP

MINI Hawk High Performance Imager User’s Manual 2-15
Using ESP
Navigating in ESP
To change imager settings, or to access the Utilities, Camera, Terminal, or Output Format
views, click the App Mode button.
To return to EZ Mode, click the EZ Mode button.
To make changes to configuration settings in the control trees:
1. Left click on the + to
expand menu items.
2. Double-click the
desired parameter and
single-click in the
selection box to view
options.
3. Place your cursor in the
selection box, scroll
down to the setting you
want to change, and
single-click the setting.
4. Left click again on the open screen to complete the
selection.
5. Right click on the open screen and select Save to
Reader to implement the command in the imager.
You can send the command without saving it, or you
can send and save the command simultaneously.
The X denotes the
default option setting.
