10-28 MINI Hawk High Performance Imager User’s Manual

Morphological Operation and Operator Size

Open

Open removes minor light defects of dark cells by performing a Dilate function followed by

an Erode function.

Close removed minor dark defects of light cells by performing an Erode function followed

by a Dilate function.
