4-16 MINI Hawk High Performance Imager User’s Manual
Initiating Calibration
Focus Pass
The purpose of
Focus Pass
is to determine the optimal focal position of the optical system.
This is accomplished by determining the inside and outside focus positions and then recording
the center position as the desired focal position.
Running Focus Pass
Prog Rating Decode Quality Focus Shutter Gain Locate
38 0 0 0 353 250 0 0
38 0 0 0 353 250 9 0
38 4256 2 48 353 250 18 5
38 0 0 0 409 250 0 0
38 4236 2 28 409 250 9 5
38 0 0 0 447 250 0 0
38 4236 2 28 447 250 9 4
38 0 0 0 492 250 0 0
38 4232 2 24 492 250 9 4
38 0 0 0 536 250 0 0
38 2128 1 24 536 250 9 5
38 0 0 0 572 250 0 0
38 0 0 0 572 250 9 0
38 2144 1 40 572 250 18 4
38 0 0 0 601 250 27 0
38 0 0 0 601 250 36 0
38 0 0 0 601 250 45 0
38 0 0 0 601 250 45 0
38 0 0 0 601 250 45 0
38 0 0 0 601 250 45 0
42 4280 2 72 297 250 45 6
42 4280 2 72 283 250 45 5
42 4280 2 72 270 250 45 5
42 4280 2 72 258 250 45 5
42 4280 2 72 247 250 45 5
42 4280 2 72 236 250 45 6
42 4280 2 72 227 250 45 5
42 4280 2 72 217 250 45 5
42 4280 2 72 209 250 45 6
42 4280 2 72 200 250 45 6
46 0 0 0 601 250 45 0
Inside Focus = 200; Outside Focus = 572; Center Focus = 386
