Monitoring ICG
15-3
Abbreviation Unit Full spelling
RCWI kg·m/m
2
Right cardiac work index
RVSW g·m Right ventricular stroke work
RVSWI g·m/m
2
Right ventricular stroke work index
EF % Ejection fraction
TFI Ω Thoracic fluid index
STR none Systolic time ratio
PEP ms Pre-ejection period
LVET ms Left ventricular ejection time
VEPT ml Volume of electrically participating tissue
15.4 Understanding the ICG Display
The ICG monitoring provides a continuous display of the impedance waveform and 4
numerics. Of 4 numerics, 1 is the primary parameter C.I. and 3 are secondary parameters. The
secondary parameters are user-selectable, and C.O., SVR and TFC are the defaults.
By selecting the ICG parameter window, you can access the [ICG Setup] menu.
ICG wave
Primary parameter Secondary parameters
