Monitoring ECG/Resp
7-18
Additionally, the 12-lead ECG monitoring has the following features:
îš„ The [Filter] mode is fixed to [Diagnostic] and cannot be changed.
îš„ The
on-screen QuickKey and the hardkey on the monitor’s front are disabled.
7.8.2 12-Lead ECG Analysis
You can only start a 12-lead ECG analysis 11 seconds after entering the 12-lead ECG
analysis program. Otherwise, the prompt message [Not enough data. Cannot analyze.] will
be displayed. In the 12-lead ECG analysis window:
îš„ Select [Freeze]. All ECG waves except the rhythm wave are frozen, and the [Freeze]
button changes to [Unfreeze].
îš„ If you want to browse the frozen ECG waves, select [Scroll] and rotate the Knob, or
select the
or button beside [Scroll].
îš„ You can print out the currently frozen waves by selecting [Record].
îš„ After the waves are frozen, you can start a 12-lead ECG analysis by selecting [Analyze].
Then, you can select [Record Result] to pint out 12-lead ECG analysis results by the
recorder, or select [Record Wave] to print out 12-lead ECG analysis results and waves.
