Monitoring SpO
2
8-3
8.3 Identifying SpO
2
Modules
To identify which SpO
2
module is incorporated into your MPM, see the company logo
located at the right upper corner as shown below:
 MPM SpO
2
module: no logo.
 Masimo SpO
2
module: Masimo SET.
 Nellcor SpO
2
module: Nellcor.
8.4 Applying the Sensor
1. Select an appropriate sensor according to the module type, patient category and weight.
2. Remove colored nail polish from the application site.
3. Apply the sensor to the patient.
4. Select an appropriate adapter cable according to the connector type and plug this cable
into the MPM.
5. Connect the sensor cable to the adapter cable.
Connector for SpO
2
cable
