Mindray BeneView T8 Operation Manual

5-1
5 User Screens
5.1 Tailoring Your Screens
You can tailor your patient monitor’s screens by setting:
 Waveform sweep mode
 Wave line size
 The color in which each measurement’s numerics and waveform are displayed
 The parameter to be monitored.
Changing some settings may be hazardous. Therefore, those setting are password-protected
and can be modified by authorized personnel only. Once change is made, those who use the
patient monitor should be notified.
5.1.1 Setting the Waveform Sweep Mode
1. Select [Main Menu]→[Screen Setup >>].
2. Select [Sweep Mode] and toggle between [Refresh] and [Scroll].
 [Refresh]: The waveforms keep stationary, with real-time refreshing from left to
right by a moving “erase bar”.
 [Scroll]: The waveforms move from the right to the left with time passing by.
5.1.2 Changing the Wave Line Size
1. Select [Main Menu]→[Maintenance >>]→[User Maintenance >>]→enter the
required password.
2. Select [Others >>].
3. Select [Wave Line] and toggle between [Thick], [Mediate] and [Thin].
5.1.3 Changing Measurement Colors
1. Select [Main Menu]→[Screen Setup >>]→[Measurement Color Setup >>].
2. Select the color box next to your desired measurement and then select a color from the
popup menu.
