Review
19-3
îš„ You can change the resolution of the trend data by selecting [Interval] and then
selecting the appropriate setting:
îš‹ [1 s]: select to view up to 1 hour of graphic trends at 1-second resolution.
îš‹ [5 s]: select to view up to 8 hours of graphic trends at 5-second resolution.
îš‹ [1 min], [5 min] or [10 min]: select to view up to 120 hours of graphic trends at
1-, 5, or 10-minute resolution.
îš„ To browse the graphic trends, you can either:
îš‹ select or to move the cursor one step to the left or right to navigate through
the graphic trends, or
îš‹ Select or to move the cursor one page to the left or right to navigate
through the graphic trends.
A time indicating your current position is displayed above the cursor. Numeric
measurement values corresponding to the cursor location appear in the left side of the
[Graphic Trends] window, and change as the cursor is moved.
îš„ By selecting the [Record] button, you can print out the currently displayed graphic
trends by the recorder.
