Review
19-9
îš‹ Select or beside the [Scroll] button to move the cursor one step left or right
to navigate through the waveforms, or
îš‹ Select or to move the cursor one page left or right to navigate through
the waveforms.
A time indicating your current position is displayed above the cursor. Numeric
measurement values corresponding to the cursor location are displayed in the left side of
the [Waveforms] window, and change as the cursor is moved.
îš„ You can change the wave gain by selecting [Gain] and then selecting the appropriate
setting. The number of waveforms displayed in this window is subject to the wave gain.
îš„ You can change the waveform sweep speed by selecting [Sweep] and then selecting the
appropriate setting.
îš„ By selecting the [Record] button, you can print out the first three waveforms and
measurement numerics.
