Sample Implementations
Figure 66 Fire alarm panel linked via SLC to master panel
1st
Floor
2nd
Floor
3rd
Floor
QX-mini
QX-mini-RM
FACP
via SLC
QX-mini-RM
QX-mini-RM
QX-mini-RM
4th
Floor
QX-mini-RM
Speakers
