Mircom QX-mini User Manual

130
15.0 Appendix E: UL Compatible Speakers
with Mircom QAD-30 QX-mini Amplifier
and Temporal 520Hz Square Wave Low
Frequency Signal
15.1 Mircom Amplifier
15.2 Mircom Temporal 520Hz Square Wave Low Frequency Signal
UL tested Mircom temporal 520Hz square wave has three matching signal inputs available in
the QX-mini Configurator library. Refer to the following table for recommended signal input
selection for UL application according to the speaker manufacturer and amplifier voltage.
Model Description
QAD-30 25 or 70 Volt 30 Watt Amplifier
Speaker/
Strobe
Manufacturer
Temporal 520Hz
Square Wave Low
Frequency Signal
Setting
Amplifier Voltage Setting
QAD-30
25V 70V
System Sensor
System Sensor 520Hz
25-70V Temporal 3
XX
System Sensor 520Hz
25-70V Temporal 4
XX
Gentex
Gentex 520Hz 25-70V
Temporal 3
XX
Gentex 520Hz 25-70V
Temporal 4
XX
Wheelock
Wheelock 520Hz 25V
Temporal 3
X
Wheelock 520Hz 25V
Temporal 4
X
Wheelock 520Hz 70V
Temporal 3
X
Wheelock 520Hz 70V
Temporal 4
X
