60
Installat
ion
Figure 30
Exploded view of QX-mini-LOC showing mounting of RAX-LCD-LITE
Door
Dead F
ront
Indicators and Controls
(RAX
-L
CD-LITE shown in
the upper window)
Backbox
Same board as
Q
X-mini-RM
Included bracket CH-980 for
RAM-3500-L
CD and RAX
-L
CD-LITE
(use 4 included standos and 4
screws attached to blank plat
e)
4 included
standos
59
61
