Mircom QX-mini - Figure 4 Mounting Screw Positions

To Next Page

To Previous Page

Installation

7. Screw the other two screws at the bottom of the panel.Tighten all four screws into place.

Figure 4 Mounting screw positions

Mount Mount

screws at screws at

these these

points points

and then and then

tighten.tighten.
