7 PARAMETER SETTINGS
7.3 Basic Settings
Connection Device Information
Set the information of the connected device.
• To connect an industrial switch (for CC-Link IE TSN Class B) to the structure of a mixture of CC-Link IE TSN Class B and
CC-Link IE TSN Class A devices, set "TSN HUB Setting" to "Use TSN HUB".
• If an industrial switch (for CC-Link IE TSN Class B) is connected with "TSN HUB Setting" set to "Not to Use TSN HUB",
device stations may not perform data link. (Page 220 A CC-Link IE TSN Class A device does not perform data link.)
Device Station Setting
Set items related to the device station.
The disconnection detection setting does not necessarily guarantee that the disconnection is performed according to the
number of times set. When disconnection is detected, a bit of the disconnected station in 'Data link status of each station'
(SW00B0 to SW00B7) turns on. However, the time required this may be at least four times the time required for the number of
consecutive communication failures set in the disconnection detection setting.
Item Description Setting range
CC-Link IE
TSN Class
Setting
Sets the CC-Link IE TSN Class of connected devices. • CC-Link IE TSN Class B Only
• Mixture of CC-Link IE TSN Class B/A or CC-Link IE TSN Class A
Only
(Default: CC-Link IE TSN Class B Only)
TSN HUB
Setting
Sets whether to use an industrial switch (for CC-Link IE TSN Class B). • Not to Use TSN HUB
• Use TSN HUB
(Default: Not to Use TSN HUB)
Item Description Setting range
Disconnection
Detection
Setting
Set the number of consecutive communication failures until a device station is considered disconnected. • 2 times
•4 times
•8 times
(Default: 4 times)
