7 PARAMETER SETTINGS
7.4 Application Settings
Supplementary Cyclic Settings
Set the station-based block data assurance and I/O maintenance settings.
Transient Transmission Group No.
Set the transient transmission group number.
Communication Mode
Set the communication mode.
Parameter Name
Set a name for the module parameter if desired.
Item Description Setting range
Station-based Block Data Assurance Select whether to ensure data integrity of the data blocks being refreshed
between the FX5 CPU module and the FX5-CCLGN-MS. ( Page 34
Cyclic data assurance)
• Enable
• Disable
(Default: Enable)
I/O Maintenance Settings Output Hold/Clear
Setting during CPU
STOP
Select whether cyclic data output is held or cleared when the FX5 CPU
module mounted with the FX5-CCLGN-MS is set to the STOP state. (
Page 40 I/O maintenance settings)
•Hold
• Clear
(Default: Hold)
Data Link Error Station
Setting
Select whether input data from the master station is held or cleared when a
data link error occurs. ( Page 40 I/O maintenance settings)
• Clear
•Hold
(Default: Clear)
Output Mode upon CPU
Error
Select whether cyclic transmission output data is held or cleared when a
stop error occurs in the FX5 CPU module mounted with the FX5-CCLGN-
MS. ( Page 40 I/O maintenance settings)
• Clear
•Hold
(Default: Clear)
Item Description Setting range
Transient Transmission Group No. Set the group number to perform transient transmission using group
specification.
0 to 32 (0: No group specification)
(Default: 0)
Item Description Setting range
Communication Mode Set the communication mode. • Unicast
•Multicast
(Default: Unicast)
Item Description Setting range
Parameter Name Set a name for the module parameter if desired. Up to 8 one-byte or two-byte
characters
(Default: empty)
