Appendix A: Special Device List

359

FX3G Series Programmable Controllers

User's Manual - Hardware Edition

Memory

Cassette

Battery

Special Devices

(M8000-,D8000-)

Instruction List

Appendix A-2 Special Data Register (D8000 to D8511)

*1. Supported in Ver. 1.10 or later.

*2. 1st expansion board becomes an expansion board

connected to BD connector of main units (14/24 point type),

or BD1 connector of main units (40/60 point type).

*3. 2nd expansion board becomes an expansion board

connected to BD2 connector of main units(40/60 point type).

*4. Connected analog special adapters are counted from the

main unit side.

*1. Supported in Ver. 1.10 or later.

*2. Latch device

Number and

name

Content of register

Correspond-

ing special

device

N:N Network (setting)

[D]8170

Not used

[D]8171 -

[D]8172 -

[D]8173 Station number -

[D]8174 Total number of slave stations -

[D]8175 Refresh range -

D 8176 Station number setting

M8038

D 8177 Total slave station number setting

D 8178 Refresh range setting

D 8179 Retry count setting

D 8180 Comms time-out setting

[D]8181 Not used -

Index Register Z1 to Z7 and V1 to V7

[D]8182 Value of Z1 register -

[D]8183 Value of V1 register -

[D]8184 Value of Z2 register -

[D]8185 Value of V2 register -

[D]8186 Value of Z3 register -

[D]8187 Value of V3 register -

[D]8188 Value of Z4 register -

[D]8189 Value of V4 register -

[D]8190 Value of Z5 register -

[D]8191 Value of V5 register -

[D]8192 Value of Z6 register -

[D]8193 Value of V6 register -

[D]8194 Value of Z7 register -

[D]8195 Value of V7 register -

[D]8196

Not used

[D]8197 -

[D]8198 -

[D]8199 -

N:N Network (monitoring)

[D]8200 Not used -

[D]8201 Current link scan time -

[D]8202 Maximum link scan time -

[D]8203

Number of communication error at

master station

M8183 to

M8191

[D]8204

Number of communication error at

slave station No.1

[D]8205

Number of communication error at

slave station No.2

[D]8206

Number of communication error at

slave station No.3

[D]8207

Number of communication error at

slave station No.4

[D]8208

Number of communication error at

slave station No.5

[D]8209

Number of communication error at

slave station No.6

[D]8210

Number of communication error at

slave station No.7

Number and

name

Content of register

Correspond-

ing special

device

[D]8211
