V5A51 -
Transmission
23E-5-18
Symbol OD mm ID mm Thickness mm Part No.
No.8 73 60 1.6 MR276705
1.8 MR276706
2.0 MR276707
2.2 MR276708
2.4 MR276709
No.9 71.4 57 2.78 MR276587
No.10 71.9 48 4.6 MR263281
No.11 54.1 34 3.83 MR276588
No.12 57 38.5 4.62 MR222936
No.13 58 37.5 4.8 MD758555
3. Install a new O-ring on the anchor plug and tighten the
anchor plug to the specified torque.
4. Install the reduction brake band.
Fit the anchor bracket hole of the brake band onto the
anchor plug tip, and then insert the apply bracket part
into the hole for reduction brake piston adjusting rod.
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
Apply bracket
Anchor bracket hole
Reduction brake piston
adjusting rod hole
Anchor plug
To Next Page
