V5A51 -
Transmission
23E-5-19
5. Install the thrust bearing No.13 onto the direct clutch
retainer.
Caution
D
Take care not to mistake the thrust bearing No.13
mounting direction.
6. Install t he direct clutch.
Caution
D
Take care that the reduction brake band does not
come off the anchor plug and the hole for the
reduction brake piston adjusting rod.
7. Install t he reduction brake spring.
8. Screw t h e reduction brake piston adjusting rod into the
reduction brake piston manually to the full.
9. Install new seal ring on the piston.
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
Thrust bearing
No.13
Thrust bearing
No.13
Direct clutch
retainer
To Next Page
