Operating the unit
36 Operating instructions
4.4.4 Inserting and removing a USB flash drive
Inserting the USB flash drive
In the case of USB flash drives which cannot be connected to
the MultiPort due to their dimensions, use an extension cable.
Requirement USB flash drive with a minimum of 2 GB and maximum of 32 GB
available storage capacity (not included with delivery)
USB flash drive not write-protected
Press the
MultiPort
cover panel on the control arm of the unit until
it disengages.
MultiPort is opened.
Insert the USB flash drive into the MultiPort.
The USB flash drive will be ready after around 5 seconds.
USB flash drive inserted.
Removing the USB flash drive
Requirement Exporting or importing of data completed
1. Remove the USB flash drive.
2. Press the
MultiPort
cover panel on the control arm of the unit until
it engages.
MultiPort is closed.
USB flash drive removed.
4426201-20ABBE-A
