NPort W2150/2250 Plus Series User’s Manual Web Console: Serial Port Settings
7-39
Serial Port Settings> Port 1 or 2> Data Buffering/Log
Each serial port on the NPort is configured in its own folder under the Serial Port Settings folder.
On the serial port’s Data Buffering/Log page, you can enable or disable Port buffering and
Serial data logging.
Port Buffering
Default
Disable
Options
Enable, Disable
Description
This field specifies whether the serial port will use port buffering when the
network connection (Ethernet or WLAN) is down. Port buffering can be used in
Real COM mode, TCP Server mode, TCP Client mode, and Pair Connection
mode. For other modes, the port buffering settings will have no effect.
Serial Data Logging
Default
Disable
Options
Enable, Disable
Description
This field specifies whether data logs for the serial port will be stored on system
RAM. Each serial port is allotted 64 KB for data logging. The data log is not
saved when the NPort is powered off.
