NPort W2150/2250 Plus Series User’s Manual Web Console: Serial Port Settings
7-38
Baud Rate
Default
115200
Options
50, 75, 110, 134, 150, 300, 600, 1200, 1800, 2400, 4800, 7200, 9600, 19200,
38400, 57600, 115200, 230400, 460800, 921600, Other
Description
This field specifies the baudrate for the serial port. Nonstandard baudrates are
supported through the “Other” setting. When set to “Other”, you may manually
enter a baudrate of your choice, up to 921600.
50 to 921600: The serial port will operate at the specified baudrate
Other: The serial port will operate at a baudrate that is manually entered by the
user.
Data Bits
Default
8
Options
5, 6, 7, 8
Description
This field specifies the number of data bits used to encode each character of
data.
Stop Bits
Default
1
Options
1, 1.5, 2
Description
This field specifies the number of stop bits used for each character frame.
Parity
Default
None
Options
None, Odd, Even, Space, Mark
Description
This field specifies the type of parity bit used for each character frame.
Flow Control
Default
RTS/CTS
Options
None, RTS/CTS, XON/XOFF, DTR/DSR
Description
This field specifies the type of flow control used by the serial port.
FIFO
Default
Enable
Options
Enable, Disable
Description
This field specifies whether the serial port will use the built-in FIFO. A 16-byte
FIFO is provided to each serial port for both Tx and Rx directions. To prevent
data loss during serial communication, this should be set to Disabled if the
attached serial device does not have a FIFO.
Interface
Default
RS-232
Options
RS-232, RS-422, RS-485 2-wire, RS-485 4-wire
Description
This field specifies the type of interface the serial port will use.
