NPort W2150/2250 Plus Series User’s Manual Getting Started
2-2
Overview
This chapter presents the hardware features of the NPort W2150/W2250 Plus Series and explains
how to connect the hardware.
Panel Layout
RJ45 10/100 Mbps
Ethernet port
DIN-Rail
screw hole
Signal Strength LEDs
Male DB9 connector
Wallmount screw hole
NPort W2250 Plus/
NPort W2250 Plus-T
NPort W2150 Plus/
NPort W2150 Plus-T
Power jack
power input
Antenna
Reset
button
Terminal Block
power input
100M LED (green) 10M LED (orange)
