NPort W2150/2250 Plus Series User’s Manual Web Console: Serial Port Settings
7-15
Allow Driver Control
Default
Disable
Options
Disable, Enable
Description
This field specifies how the port will proceed if driver control commands are
received from multiple hosts that are connected to the port.
Disable: Driver control commands will be ignored.
Enable: Control commands will be accepted, with the most recent command
received taking precedence.
TCP Port
Default
4001
Options
0 to 9999
Description
This field specifies the TCP port number that the serial port will use to listen to
connections, and that other devices must use to contact the serial port.
Cmd Port
Default
996
Options
0 to 9999
Description
This field specifies the TCP port number for listening to SSDK commands from
the host.
Connection Goes Down
Default
always high
Options
always low, always high
Description
This field specifies what happens to the RTS and DTR signals when the
Ethernet connection goes down. For some applications, serial devices need to
know the Ethernet link status through RTS or DTR signals sent through the
serial port.
Always low: The selected signal will change to low when the Ethernet
connection goes down.
Always high The selected signal will remain high when the Ethernet connection
goes down.
