NPort W2150/2250 Plus Series User’s Manual Web Console: Serial Port Settings
7-20
Designated Local Port 1 to 4
Default
Options
1 to 65535
Description
This field specifies the TCP port number that will be used for data transmission
with the serial port.
Connection Control
Default
Startup/None
Options
Startup/None, Any Character/None, Any Character/Inactivity Time, DSR
On/DSR Off, DSR On/None, DCD On/DCD Off, DCD On/None
Description
This field specifies how connections to the device are established and closed.
Startup/None: The connection will be opened as the NPort starts up. The
connection will only be closed manually.
Any Character/None: The connection will be opened as soon as a character is
received from the attached device. The connection will only be closed
manually.
Any Character/Inactivity Time: The connection will be opened as soon as a
character is received from the attached device. The connection will be closed if
no data is received for the time specified in Inactivity time.
DSR On/DSR Off: The TCP connection is opened when the DSR signal is on,
and closed when the DSR signal is off.
DSR On/None: The TCP connection is opened when the DSR signal is on. The
connection will only be closed manually.
DCD On/DCD Off: The TCP connection is opened when the DCD signal is on,
and closed when the DCD signal is off.
DCD On/None: The TCP connection is opened when the DCD signal is on. The
connection will only be closed manually.
Packet Length
Default
0
Options
0 to 1024
Description
This field specifies the maximum amount of data that is allowed to accumulate
in the serial port buffer before sending.
0: Packet length is disregarded and data in the buffer will be sent as specified by
the delimiter settings or when the buffer is full.
1 to 1024: Data in the buffer will be sent as soon it reaches the specified length.
