13 Technical data
Maschinenfabrik Reinhausen GmbH 2022194 8595028/00 ENTAPCON
®
250
Interface Pin Description
1
2
3
4
4 V2U- voltage input
3 V2I- current input
2 V2 I+ current output
1 V2U+ voltage output
Table84: ConnectorX3 (group 2)
Interface Pin Description
1
2
3
4
4 V3U- voltage input
3 V3I- current input
2 V3 I+ current output
1 V3U+ voltage output
Table85: ConnectorX4 (group 3)
13.2.10 Analog outputs AO 4
AI4
Outputs (electrically isolated) 4 x 1¹
Signal range Max. -10...+10V on min. 1kΩ load
Max. -10...+10mA on max. 500Ω load
Max. -20…+20mA on max. 1kΩ load
Accuracy 0.3% at 25°C
0.4% at 0°C to 50°C
0.7% at -20°C to 70°C
0.8% at -40°C to 70°C
Table86: AO4 assembly technical data
¹) In combination with PS-8620, 2 of 4 outputs will be used at the same time
Interface Pin Description
1
2
3
4
4 Not used
3 V0- current input
2 V0+ current output
1 Not used
Table87: ConnectorX1 (group 0)
