4 Product description
Maschinenfabrik Reinhausen GmbH 202234 8595028/00 ENTAPCON
®
250
4.4.3.1.9 Analog outputs AO 4
The AO4 assembly provides you with 4analog outputs for issuing measure-
ment values (-20...+20mA, -10...+10V). The RY LED signals that the as-
sembly is ready for operation.
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
X1
X2
X3
X4
SICAM A8000
AI - 8380
RY
Figure17: AO4 assembly
4.4.3.1.10 Voltage measurement U 3
The U3 assembly is used for measuring 1-phase voltage. The RY LED sig-
nals that the assembly is ready for operation.
1
2
3
4
5
6
7
8
9
10
X2
RY
SICAM A8000
AI - 8340
1
2
3
4
X1
Figure18: U3 assembly
