4 Product description
Maschinenfabrik Reinhausen GmbH 2022 418595028/00 EN TAPCON
®
250
Desired values/actual values/delay time
1
5
2
4
3
Figure28: Display
1 Upper limit of bandwidth 2 Delay time T1/T2
3 Display of the measured voltage
and corrected voltage (correction
due to compensation or parallel
operation)
4 Lower limit of bandwidth
5 Desired value
4.4.8.2 Operating concept
You can operate the device using the controls on the front panel or using the
web-based Intuitive Control Interface visualization on a PC. The scope of
function and structure of both options is virtually identical.
User rights and user roles
The device is equipped with a rights system and a roles system. The display
and access rights to device settings or events can therefore be controlled at
the user level. You can configure the rights system and roles system to meet
your requirements. You will find more information in the User administration
section.
You can only modify the device settings or parameters if you have the nec-
essary user rights.
