List of specifications 163

Dimensions Height 1,428 mm

(When installing ink bag cases: 1,611 mm)

Width 2,750 mm

Depth 895 mm

Weight Main body XPJ-1641SR: 142 kg

XPJ-1682SR: 146 kg

Stand 32 kg
