PROGRAMMABLE KEYS
Speed Dial and Programmable Keys
7 -76 DT820 Phone User Guide
If you have Visual monitor settings for a Speed Dial entry, the presence (Available,
Busy or Offline) of the line is shown by the LED Color.
Table 7.6 Monitor Presence LED Colors for Speed Dial Keys
BLF Idle
Ringing (SIP@Net)
Ringing (3C system)
Subscription Failed
Online (3C system)
(Phone is Online)
On the Phone
(Phone is in use)
Held (3C system)
Busy
Type Status
Programmable
Key LED
Line Key Registered LED is not lit
Unregistered LED is not lit
Speed Dial Key
(No Monitoring)
Not Available LED is not lit
Type Status Icon
To Next Page
