NETGEAR Nighthawk D7000 User Manual

DescriptionField
network but limits 802.11ac devices to function at up to
600 Mbps.
•
Up to 1300 Mbps. Performance mode.This mode allows
802.11ac, 802.11na, and 802.11a devices to join the
network and allows 802.11ac devices to function at up to
1300 Mbps.This mode is the default mode.
By default, the modem router broadcasts its SSID so that WiFi
stations can detect the WiFi name (SSID) in their scanned
Enable SSID Broadcast
network lists.To turn off the SSID broadcast, clear the Enable
SSID Broadcast check box.Turning off the SSID broadcast
provides additional WiFi security, but users must know the SSID
to be able to join the WiFi network of the modem router.
Security Options
This information applies to the 5 GHz WiFi network.
NETGEAR recommends that you do not change your preset security settings (WPA2-
PSK [AES]).
Note
If you must change the WiFi security, select one of the following WiFi security options for the modem
router’s WiFi network:
•
None. An open WiFi network that does not provide any security. Any WiFi device can join the
network. NETGEAR recommends that you do not use an open WiFi network.
•
WPA2-PSK [AES].This option is the default setting. This type of security enables WiFi devices
that support WPA2 to join the modem router’s 5 GHz WiFi network. If you did not change the
passphrase, the default passphrase displays. The default passphrase is printed on the product
label (see Bottom Panel Product Label on page 17). WPA2 provides a secure connection but
some older WiFi devices do not detect WPA2 and support only WPA. If your network includes
such older devices, select WPA-PSK [TKIP] + WPA2-PSK [AES] security.
NETGEAR recommends that you do not change the default passphrase. If you must change the
passphrase, in the Passphrase field, enter a phrase of 8 to 63 characters.To join the modem
router’s WiFi network, a user must enter this passphrase.
•
WPA-PSK [TKIP] + WPA2-PSK [AES].This type of security enables WiFi devices that support
either WPA or WPA2 to join the modem router’s 5 GHz WiFi network. However, WPA-PSK [TKIP]
is less secure than WPA2-PSK [AES] and limits the speed of WiFi devices to 54 Mbps.
Manage the WiFi Network Settings
108
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
