DescriptionField
NAT allows computers on your home network to share the modem router Internet connection. NAT
is enabled by default because it is required in most situations. Select the NAT setting:
•
Enable. NAT is enabled.This is the default setting. Leave this setting if no reason to disable NAT
exists.
•
Disable. NAT is disabled.
Router MAC Address
The Ethernet MAC address that the modem router uses on the Internet port. Some ISPs register the
MAC address of the network interface card in your computer when your account is first opened.They
accept traffic only from the MAC address of that computer.
This feature allows your modem router to use your computer’s MAC address (also called cloning).
Use the default MAC address.Use Default Address
The modem router captures and uses the MAC address of the
computer that you are now using.You must use the one computer
that is registered by the ISP.
Use Computer MAC Address
Enter the MAC address that you want to use. By default, the field
displays the MAC address of the Internet port.
Use This MAC Address
13. Click the Apply button.
Your settings are saved.
14. Click the Test button to test your Internet connection.
If the NETGEAR website does not display within one minute, see Troubleshoot the Internet Connection
on page 299.
Manually Set Up a Cable or Fiber Internet Connection
You can view or change the modem router’s cable or fiber Internet connection settings manually.The
following sections describe the options that are available to you to manually set up the cable or fiber
Internet connection:
Manage the Internet Settings Manually
73
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

Table of Contents

Other manuals for NETGEAR Nighthawk D7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk D7000 and is the answer not in the manual?

NETGEAR Nighthawk D7000 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1300 Mbit/s
USB version3.2 Gen 1 (3.1 Gen 1)
Rack mountingNo
Bandwidth (first)2.4 GHz
Bandwidth (second)5 GHz
USB ports quantity2
WLAN data transfer rates supported600, 1300 Mbit/s
Memory card slot(s)-
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports5
DSL specificationVDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity3
Security algorithmsWPA, WPA2-PSK, WPS
Product typeTabletop router
Product colorBlack
Flash memory128 MB
Internal memory256 MB
Processor frequency1000 MHz
Cables includedLAN (RJ-45)
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth185 mm
Width285 mm
Height50 mm
Weight750 g
