If the NETGEAR website does not display within one minute, see Troubleshoot the Internet Connection
on page 299.
Specify an ADSL Connection with a Login Requirement and
PPPoA or PPPoE Service
If you want to manually configure the ADSL connection settings, use the information that your ISP gave
you to log in and connect to your Internet service. If you cannot find this information, contact your ISP.
Entering incorrect information might prevent the modem router from connecting to the Internet.
The modem router provides a virtual Internet interface and a virtual IPTV interface. In most situations,
you only need to configure the Internet interface. If you use one or more IPTV devices, you might also
need to configure the IPTV interface. Follow the directions that your ISP gave you.
If you must configure the IPTV interface, first use the following procedure to configure
the Internet interface.Then, repeat the procedure to configure the IPTV interface.
Note
To view or specify the settings for an ADSL Internet connection that requires a login and uses a
PPPoE or PPPoA service:
1. Launch an Internet browser from a computer or WiFi device that is connected to the network.
2. Type http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select Internet.
The Internet Setup page displays.
6. From the Select Country menu, select the country in which you use the modem router.
The Select Country menu is not available in all countries and might be masked out.
7. From the Select Internet Service Provider menu, select the Internet service provider (ISP) that you
are using.
If your ISP is not in the menu, select Other.
8. Select the virtual interface:
Manage the Internet Settings Manually
57
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
