DescriptionField or Column
The statistics for the WAN (Internet over Ethernet) port, LAN (Ethernet)
ports, WLAN b/g/n port, and WLAN a/n/ac port. For each port, the
screen displays the information that is described in this table.
Port
The link status of the port.Status
The number of packets that were transmitted on this port since reset
or manual clear.
TxPkts
The number of packets that were received on this port since reset or
manual clear.
RxPkts
The number of packets that collided on this port since reset or manual
clear.
Collisions
The number of bytes per second that were transmitted on this port
since reset or manual clear.
Tx B/s
The number of bytes per second that were received on this port since
reset or manual clear.
Rx B/s
The time elapsed since this port acquired the link.Up Time
ADSL Link
In addition to the xDSL firmware version, the screen displays the ADSL link information that is
described in this table.
The downstream and upstream link rates in Kbps.Link Rate
The downstream and upstream Line Attenuation (LATN) in dB.The
LATN expresses the signal quality.
Line Attenuation
The downstream and upstream Signal-to-Noise Ratio Margin (SNRM)
in dB.The SNRM expresses the signal quality in relation to interference.
Noise Margin
The interval at which the statistics are updated in this screen.Poll Interval
Change the Traffic Statistics Polling Frequency
You can change the polling frequency or stop traffic polling.
Manage the Modem Router and Monitor the Traffic
248
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
