To display the wired and WiFi devices:
1. Launch an Internet browser from a computer or WiFi device that is connected to the network.
2. Type http://www.routerlogin.net.
A login window opens.
3. Enter the user name and password for the modem router.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select BASIC > Attached Devices.
The Attached Devices page displays.
Wired devices are connected to the modem router with Ethernet cables.WiFi devices are connected
to the modem router through the WiFi network, in either the 2.4 GHz band or the 5 GHz band.
The following table describes the fields on the Attached Devices page.
DescriptionField
The status of the device in the network (Allowed or Blocked).Status
The device name, if detected.Device Name
The IP address that the modem router assigned to the device when it
joined the network. This number can change when a device is
disconnected and rejoins the network.
IP Address
The unique MAC address. The MAC address does not change and is
usually shown on the product label.
MAC Address
6. To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
Manage the Activity Log and Syslog
The log is a detailed record of the websites users on your network accessed or attempted to access and
many other modem router actions. Up to 256 entries are stored in the log.You can manage which activities
are logged.
Manage the Modem Router and Monitor the Traffic
252
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
