The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select ADVANCED > ADVANCED Home.
The ADVANCED Home page displays.
6. In the Internet Port pane, click the Connection Status button.
The Connection Status pop-up window opens. The fields that display depend on the type of Internet
connection.
The following table describes the fields for a PPPoE connection.
DescriptionField
The time elapsed since the connection was established.Connection Time
The status can be Connected or Disconnected.Connection Status
The negotiation can be a series of dashes, which indicates that the
connection is not established, or successful (Success).
Negotiation
The authentication can be a series of dashes, which indicates that the
connection is not established, or successful (Success).
Authentication
The IP address that is assigned by the ISP to the modem router.IP Address
The subnet mask that is assigned by the ISP to the modem router.Subnet Mask
7. To establish the Internet connection when the connection is down, click the Connect button.
8. To terminate the Internet connection when the connection is active, click the Disconnect button.
9. Click the Close Window button.
The pop-up window closes.
View Devices Currently on the Network
You can view the active wired and WiFi devices in both the network to which the modem router is connected
and the modem router network. If you do not recognize a WiFi device, it might be an intruder.
Manage the Modem Router and Monitor the Traffic
251
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
