NETGEAR Nighthawk D7000 User Manual

DescriptionField
To use WPA + WPA2 security, in the Passphrase field, enter a phrase of 8 to 63 characters.To
join the 5 GHz band of the guest WiFi network, a user must enter this passphrase.
•
WPA/WPA2 Enterprise.This type of security requires that your WiFi network can access a
RADIUS server. For information about configuring WPA/WPA2 Enterprise, see Configure
WPA/WPA2 Enterprise WiFi Security on page 109.
The passphrase that provides users access to the guest
WiFi network in the 5 GHZ band. The passphrase is also
referred to as the password or key.
Passphrase
6. Click the Apply button.
Your settings are saved.
7. Make sure that you can reconnect over WiFi to the guest network.
If you cannot connect over WiFi, check the following:
•
If your computer or WiFi device is already connected to another WiFi network in your area, disconnect
it from that WiFi network and connect it to the WiFi network that the modem router provides. Some
WiFi devices automatically connect to the first open network without WiFi security that they discover.
•
Does your WiFi device display as an attached device? (See View Devices Currently on the Network
on page 251.) If it does, it is connected to the network.
•
Are you using the correct network name (SSID) and password?
Control the WiFi Radios
The modem router provides internal WiFi radios that broadcast signals in the 2.4 GHz and 5 GHz ranges.
By default, they are on so that you can connect over WiFi to the modem router.When the WiFi radios are
off, you can still use an Ethernet cable for a LAN connection to the modem router.
You can turn the WiFi radios on and off with the WiFi On/Off button on the modem router, or you can log
in to the modem router and enable or disable the WiFi radios through the web management interface. If
you are close to the modem router, it might be easier to press the WiFi On/Off button. If you are away
from the modem router or already logged in, it might be easier to enable or disable the radios through the
web management interface.You can also turn the WiFi radios off and on based on a schedule. (See Set
Up a WiFi Schedule on page 125.)
Manage the WiFi Network Settings
123
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
