A login window opens.
3. Enter the user name and password for the modem router.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select ADVANCED > Setup > LAN Setup.
The LAN Setup page displays.
6. From the RIP Direction menu, select an RIP direction:
•
Both.The modem router broadcasts its routing table periodically and incorporates information that
it receives.This is the default setting.
•
Out Only.The modem router broadcasts its routing table periodically but does not incorporate the
RIP information that it receives.
•
In Only.The modem router incorporates the RIP information that it receives but does not broadcast
its routing table.
7. From the RIP Version menu, select an RIP version:
•
Disabled.The RIP version is disabled. This is the default setting.
•
RIP-1.This format is universally supported. It is adequate for most networks, unless you are using
an unusual network setup.
•
RIP-2.This format carries more information. Both RIP-2B and RIP-2M send the routing data in
RIP-2 format. RIP-2B uses subnet broadcasting. RIP-2M uses multicasting.
8. Click the Apply button.
Your settings are saved.
Manage Reserved LAN IP Addresses
When you specify a reserved IP address for a computer on the LAN, that computer always receives the
same IP address each time it accesses the modem router’s DHCP server.
Reserve a LAN IP address
You can assign a reserved IP address to a computer or server that requires permanent IP settings.
Manage the WAN and LAN Network Settings
222
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
