prefix, which is also indicated by the underline (_) under the IPv6 address. If no address is acquired,
the field displays Not Available.
• Router’s IPv6 Address On LAN.This field shows the IPv6 address that is acquired for the modem
router’s LAN interface. The number after the slash (/) is the length of the prefix, which is also
indicated by the underline (_) under the IPv6 address. If no address is acquired, the field displays
Not Available.
7. If your ISP gave you a specific user class, in the DHCP User Class (If Required) field, enter the user
class.
If your ISP did not give you a specific user class, leave this field blank.
8. To specify a domain name, in the DHCP Domain Name field, enter a domain name.
If your ISP gave you a specific domain name, enter it in this field. (For example, Earthlink Cable might
require a host name of home, and Comcast sometimes supplies a domain name.)
If your ISP did not give you a specific domain name, you can either leave this field blank or enter the
domain name of your IPv6 ISP. (Do not enter the domain name for the IPv4 ISP here.) For example,
if your ISP’s mail server is mail.xxx.yyy.zzz, enter xxx.yyy.zzz as the domain name.
9. Select an IP Address Assignment radio button:
•
Use DHCP Server.The modem router assigns IPv6 addresses to the devices on your home network
(the LAN) through a DHCP server.This method passes more information to LAN devices, but some
IPv6 systems might not support the DHCPv6 client function.
•
Auto Config. This is the default setting.
10. To specify the interface ID for the IPv6 address of the modem router’s LAN interface, select the Use
This Interface ID check box, and enter the interface ID.
If you do not specify an ID here, the modem router generates one automatically from its MAC address.
11. Select the IPv6 filtering mode:
•
Secured. In secured mode, which is the default mode, the modem router inspects both TCP and
UDP packets.
•
Open. In open mode, the modem router inspects UDP packets only.
12. Click the Apply button.
Your settings are saved.
Manage the MTU Size
The maximum transmission unit (MTU) is the largest data packet a network device transmits.
Manage the Internet Settings Manually
98
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
