NETGEAR Nighthawk D7000 User Manual

DescriptionField
To use this type of security, in the Passphrase field, enter a phrase of 8 to 63 characters.To join
the modem router’s WiFi network, a user must enter this passphrase.
•
WPA/WPA2 Enterprise.This type of security requires that your WiFi network can access a
RADIUS server. For information about configuring WPA/WPA2 Enterprise, see Configure
WPA/WPA2 Enterprise WiFi Security on page 109.
7. Click the Apply button.
Your settings are saved.
If you connected over WiFi to the network and you changed the SSID, you are disconnected from the
network.
8. Make sure that you can reconnect over WiFi to the network with its new settings.
If you cannot connect over WiFi, check the following:
•
If your computer or WiFi device is already connected to another WiFi network in your area, disconnect
it from that WiFi network and connect it to the WiFi network that the modem router provides. Some
WiFi devices automatically connect to the first open network without WiFi security that they discover.
•
If your computer or WiFi device is trying to connect to your network with its old settings (before you
changed the settings), update the WiFi network selection in your computer or WiFi device to match
the current settings for your network.
•
Does your WiFi device display as an attached device? (See View Devices Currently on the Network
on page 251.) If it does, it is connected to the network.
•
Are you using the correct network name (SSID) and password?
Configure WPA/WPA2 Enterprise WiFi Security
Remote Authentication Dial In User Service (RADIUS) is an enterprise-level method for centralized
Authentication, Authorization, and Accounting (AAA) management. To provide WPA/WPA2 enterprise
WiFi security, the WiFi network that the modem router provides must be able to access a RADIUS server.
If you want to change the WiFi settings of the modem router’s main network, use a wired
connection to avoid being disconnected when the new WiFi settings take effect.
Tip
To configure WPA/WPA2 enterprise security:
1. Launch an Internet browser from a computer or WiFi device that is connected to the network.
2. Type http://www.routerlogin.net.
Manage the WiFi Network Settings
109
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
