Use DHCP Server.The modem router assigns IPv6 addresses to the devices on your home network
(the LAN) through a DHCP server.This method passes more information to LAN devices, but some
IPv6 systems might not support the DHCPv6 client function. This is the default setting.
•
Auto Config. The modem router automatically configures its IPv6 address based on the IPv6
protocol.
9. To specify the interface ID for the IPv6 address of the modem router’s LAN interface, select the Use
This Interface ID check box, and enter the interface ID.
If you do not specify an ID here, the modem router generates one automatically from its MAC address.
10. Select the IPv6 filtering mode:
•
Secured. In secured mode, which is the default mode, the modem router inspects both TCP and
UDP packets.
•
Open. In open mode, the modem router inspects UDP packets only.
11. Click the Apply button.
Your settings are saved.
Set Up an IPv6 Pass-Through Connection
In IPv6 pass-through mode, the modem router works as a Layer 2 Ethernet switch with two ports (LAN
and WAN Ethernet ports) for IPv6 packets.The modem router does not process any IPv6 header packets.
Follow the directions that your IPv6 ISP gave you.Note
To set up an IPv6 pass-through Internet connection:
1. Launch an Internet browser from a computer or WiFi device that is connected to the network.
2. Type http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select ADVANCED > Advanced Setup > IPv6.
Manage the Internet Settings Manually
89
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
