You might find the MAC address on the product label of your device. Enter the MAC address
in the AABBCCDDEEFF format, not in the AA:BB:CC:DD:EE:FF format.
d. Click the Next button.
13. If the Congratulations! window still does not display and the modem router still does not connect to
the Internet, do the following:
a. Review all your settings and make sure that you selected the correct options and entered everything
correctly.
b. Run the Setup Wizard one more time.
c. Contact your ISP to verify that you are using the correct configuration information.
d. Read Troubleshoot the Internet Connection on page 299.
e. If problems persist, register your NETGEAR product and contact NETGEAR technical support.
Manually Set Up an ADSL Internet Connection
You can view or change the modem router’s ADSL Internet connection settings manually.The following
sections describe the options that are available to you to manually set up the ADSL Internet connection:
• Specify an ADSL Connection Without a Login Requirement on page 51
• Specify an ADSL Connection with a Login Requirement and PPPoA or PPPoE Service on page 57
Some ISPs require that you register on their website before you can obtain Internet
service. Follow the directions that your ISP gave you.
Note
Specify an ADSL Connection Without a Login Requirement
If you want to manually configure the ADSL connection settings, use the information that your ISP gave
you to connect to your Internet service. If you cannot find this information, contact your ISP. Entering
incorrect information might prevent the modem router from connecting to the Internet.
The modem router provides a virtual Internet interface and a virtual IPTV interface. In most situations,
you only need to configure the Internet interface. If you use one or more IPTV devices, you might also
need to configure the IPTV interface. Follow the directions that your ISP gave you.
If you must configure the IPTV interface, first use the following procedure to configure
the Internet interface.Then, repeat the procedure to configure the IPTV interface.
Note
To view or specify the settings for an ADSL Internet connection that does not require a login:
1. Launch an Internet browser from a computer or WiFi device that is connected to the network.
2. Type http://www.routerlogin.net.
Manage the Internet Settings Manually
51
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
