A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select Internet.
The Internet Setup page displays.
6. From the Select Country menu, select the country in which you use the modem router.
The Select Country menu is not available in all countries and might be masked out.
7. From the Select Internet Service Provider menu, select the Internet service provider (ISP) that you
are using.
If your ISP is not in the menu, select Other.
8. Select the virtual interface:
•
Internet interface. From the menu above the Enable This Interface check box, leave the default
menu selection at Internet.
• IPTV interface. From the menu above the Enable This Interface check box, select IPTV.
9. From the Transfer Mode menu, select ADSL(ATM).
10. From the DSL Mode menu, select the ADSL mode that your ISP provided you:
•
Auto. The modem router detects the DSL mode automatically. (This is the default setting.)
•
ADSL. Legacy version of ADSL.
•
ADSL2. Legacy version of ADSL2.
•
ADSL2+. ADSL2+ provides the fastest downstream rates and can interoperate with ADSL2 and
ADSL.
11. Specify that your ISP does not require you to log in:
•
If you are configuring the Internet interface, scroll down to the Does your Internet connection require
a login? section and select the No radio button.
•
If you are configuring the IPTV interface, scroll down to the Does your IPTV connection require a
login? section and select the No radio button.
12. Make sure that the Enable This Interface check box is selected.
Manage the Internet Settings Manually
52
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000
