NETGEAR Nighthawk D7000 User Manual

DescriptionField
Enter the MAC address that you want to use. By default, the field
displays the MAC address of the Internet port.
Use This MAC Address
14. Click the Apply button.
Your settings are saved.
15. Click the Test button to test your Internet connection.
If the NETGEAR website does not display within one minute, see Troubleshoot the Internet Connection
on page 299.
Manually Set Up a VDSL Internet Connection
You can view or change the modem router’s VDSL Internet connection settings manually.The following
sections describe the options that are available to you to manually set up the VDSL Internet connection:
• Specify a VDSL Connection Without a Login Requirement on page 63
• Specify a VDSL Connection with a Login Requirement and PPPoE Service on page 68
Some ISPs require that you register on their website before you can obtain Internet
service. Follow the directions that your ISP gave you.
Note
Specify a VDSL Connection Without a Login Requirement
If you want to manually configure the VDSL connection settings, use the information that your ISP gave
you to connect to your Internet service. If you cannot find this information, contact your ISP. Entering
incorrect information might prevent the modem router from connecting to the Internet.
The modem router provides a virtual Internet interface and a virtual IPTV interface. In most situations,
you only need to configure the Internet interface. If you use one or more IPTV devices, you might also
need to configure the IPTV interface. Follow the directions that your ISP gave you.
If you must configure the IPTV interface, first use the following procedure to configure
the Internet interface.Then, repeat the procedure to configure the IPTV interface.
Note
To view or specify the settings for a VDSL Internet connection that does not require a login:
1. Launch an Internet browser from a computer or WiFi device that is connected to the network.
2. Type http://www.routerlogin.net.
Manage the Internet Settings Manually
63
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR Nighthawk D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
Memory card slot(s)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity	3
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Power source type	AC

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
