The user name is admin.The default password is password. The user name and password are
case-sensitive.
4. Click the OK button.
The BASIC Home page displays.
5. Select ADVANCED > Advanced Setup > Static Routes.
The Static Routes page displays.
6. Click the Add button.
7. To make the route private, select the Private check box.
A private static route is not reported in RIP.
8. To prevent the route from becoming active after you click the Apply button, clear the Active check
box.
In some situations, you might want to set up a static route but keep it disabled until a later time. By
default, the Active check box is selected and a route becomes active after you click the Apply button.
9. Enter the settings as described in the following table.
DescriptionField
Enter the IP address for the final destination of the route.Destination IP Address
Enter the IP subnet mask for the final destination of the route.IP Subnet Mask
If the destination is a single host, enter 255.255.255.255.
Manage the WAN and LAN Network Settings
229
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

Table of Contents

Other manuals for NETGEAR Nighthawk D7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk D7000 and is the answer not in the manual?

NETGEAR Nighthawk D7000 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1300 Mbit/s
USB version3.2 Gen 1 (3.1 Gen 1)
Rack mountingNo
Bandwidth (first)2.4 GHz
Bandwidth (second)5 GHz
USB ports quantity2
WLAN data transfer rates supported600, 1300 Mbit/s
Memory card slot(s)-
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports5
DSL specificationVDSL, VDSL2, ADSL, ADSL2, ADSL2+
Antennas quantity3
Security algorithmsWPA, WPA2-PSK, WPS
Product typeTabletop router
Product colorBlack
Flash memory128 MB
Internal memory256 MB
Processor frequency1000 MHz
Cables includedLAN (RJ-45)
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth185 mm
Width285 mm
Height50 mm
Weight750 g
