Chapter 5 Troubleshooting
113
5.2 Troubleshooting for the Units
5.2.1 Microscope Main Body
Problem Check item
Power cannot be turned on even when
the power switch is pressed.
󱹕
Correctly connect the AC adapter and the power cord. (
7.15.1)
No instructions on the AUX port
󱹕
The AUC port might be set to R80 (right side port 80%, eyepiece observation port
20%) or L80 (left side port 80%, eyepiece observation port 20%) according to the
specification at the time of purchase. (
3.2.1)
The precentered lamphouse cannot be
controlled from the main body.
󱹕
Correctly connect the cable for the lamphouse. (
7.15.1)
󱹕
Correctly connect the power supply and the Ti2-U. (
7.15.1)
󱹕
Turn on the EXTERNAL switch of the power supply. (
3.3.7)
5.2.2 Problems with the Dia-illumination Section
LED Lamp House for Dia Illumination
Problem Check item
When dia-illumination is turned on,
illumination does not reach the
specimen.
󱹕
Open the dia-illumination shutter. (
3.3.1)
󱹕
Remove the shutter of the condenser unit from the optical path. (
3.4.6)
󱹕
Open the filed diaphragm and the aperture diaphragm. (
3.3.3, 3.4.5)
The LED illumination is too bright.
󱹕
Insert the ND32 filter supplied with the LED lamphouse into the fixed filter slot.
(
7.8.3)
D-LH/LC precentered lamphouse
Problem Check item
Pressing the dia-illumination ON/OFF
button does not turn on the
dia-illumination.
󱹕
Correctly connect the cable for the lamphouse. (
7.15.1)
󱹕
Check whether the lamp is broken. (
7.8.7)
When dia-illumination is turned on,
illumination does not reach the
specimen.
󱹕
Open the dia-illumination shutter. (
3.3.1)
󱹕
Open the motorized shutter if it is in use. (
3.3.7)
󱹕
Remove the shutter of the condenser unit from the optical path. (
3.4.6)
Brightness of diascopic illumination
cannot be adjusted using the
dia-illumination brightness adjuster.
󱹕
Correctly connect the cable for the lamphouse. (
7.15.1)
󱹕
Turn on the EXTERNAL switch of the power supply. (
3.3.7)
󱹕
Correctly connect the power supply and the Ti2-U. (
7.15.1)
The lamp is burnt out immediately after
dia-illumination is turned on.
󱹕
Check whether an unsupported lamp is in use.
